Product Title:

AlDimming 21W 0/1-10V Dimmable LED Driver (PE-N20ACA42) – Adjustable Current (200mA-500mA)

Approximate Price: ₹550 – ₹950 per unit (varies by vendor and quantity)

Key Specifications:

• Model: PE-N20ACA42

• Power: 21 Watts (Max)

• Input Voltage: 100-250V AC, 50/60Hz

• Output Voltage: 25-42V DC

• Output Current: Adjustable 200mA to 500mA (via DIP switches)

• Dimming Type: 0-10V / 1-10V / PWM / Resistor (Works with smart dimming systems)

• Manufacturer: Guangdong AlDimming Electronics Co., Ltd.

Key Features (Why choose this over the BAG driver?)

1. Adjustable Brightness (Dimming): Unlike the previous BAG driver, this unit supports 0-10V dimming. It connects to wall dimmers or smart home automation systems to lower the lights.

2. Adjustable Current (DIP Switches): You don’t need to buy a specific 1000mA or 500mA driver. You can manually set the output current using the small white switches (table printed on the cover):

   • Example: Set switches to ON-ON-ON for 500mA output.

   • Example: Set switches to OFF-OFF-OFF for 200mA output.

3. Universal Input: Works on a wide voltage range (100V-250V), making it stable even with voltage fluctuations.
